Juicer circuit board development

果汁机电路板开发1.该家电控制板果汁机电路板采用MCU控制,具有存储和多功能果汁功能,以下结合整机说明电路板功能。液晶玻璃(实际液晶玻璃为英文字符)和蓝色背光源显示。2.14个按键和15个LED,除了“ON/OFF”按键有红白LED各一个,其它按键分别有一个对应白LED。3.可控硅选用BTA24。4.额定电压:AC110V  50/60Hz5.用电压:110V±20%  50/

  • Model: Juicer circuit board development

果汁机电路板开发

1.该家电控制板果汁机电路板采用MCU控制,具有存储和多功能果汁功能,以下结合整机说明电路板功能。液晶玻璃(实际液晶玻璃为英文字符)和蓝色背光源显示。

2.14个按键和15个LED,除了“ON/OFF”按键有红白LED各一个,其它按键分别有一个对应白LED。

3.可控硅选用BTA24。

4.额定电压:AC110V  50/60Hz

5.用电压:110V±20%  50/60Hz

6.工作环境:0~45℃  95%湿度

7.负载(整机):1680W

8.关机状态功耗:<1W


Juicer circuit board development

Development of juicer circuit board

1. The Juicer circuit board of the household appliances control board is controlled by MCU, which has the functions of storage and multi-function juice. The following is a description of the circuit board function combined with the whole machine. LCD glass (actual LCD glass is English character) and blue backlight display.

2.14 keys and 15 LEDs, except "ON/OFF" keys have one red and one white LED, the other keys have one corresponding white LED.

3. BTA24 is selected for thyristor.

4. Rated voltage: AC110V 50/60Hz

5. Voltage: 110V + 20% 50/60Hz

6. Working environment: 95% humidity at 0-45 C

7. Load (whole machine): 1680W

8. Power consumption in shutdown state:<1W
